Synthetic tooth enamel could shield stuff from vibration

Play Video

Designing rigid structures to mimic tooth enamel could prevent the aging and cracking caused by vibration, such as a flight computer on an airplane.

Most materials that effectively absorb vibration are soft, so they don’t make good structural components such as beams, chassis, or motherboards. For inspiration on how to make hard materials that survive repeated shocks, the researchers looked to nature.

“Artificial enamel is better than solid commercial and experimental materials that are aimed at the same vibration damping,” says Nicholas Kotov, professor of chemical engineering at the University of Michigan. “It’s lighter, more effective, and, perhaps, less expensive.”

T rex tooth
The tooth of a Tyrannosaurus rex. (Credit: Kotov Lab/U. Michigan)

Designed to last

He and his team didn’t settle on enamel immediately. They examined many structures in animals that had to withstand shocks and vibrations: bones, shells, carapaces, and teeth. These living structures changed from species to species and over the eons.

Tooth enamel tells a different story. Under an electron microscope, it shares a similar structure whether it comes from a Tyrannosaurus, a walrus, a sea urchin, or Kotov himself (he contributed his own wisdom tooth to the effort).

“To me, this is opposite to what’s happening with every other tissue in the process of evolution,” he says. “Their structures diversified tremendously but not the structure of enamel.”

Sharks and people have the same teeth-growing cells

Evolution hit on a design that worked for pretty much everyone with teeth. And unlike bone, which can be repaired, enamel has to last the lifetime of the tooth—years, decades, or longer still. It must withstand repeated stresses and general vibrations without cracking.

Enamel is made of columns of ceramic crystals infiltrated with a matrix of proteins, set into a hard protective coating. This layer is sometimes repeated, made thicker in the teeth that have to be tougher.

T rex tooth enamel
An electron microscope image of the enamel of a Tyrannosaurus rex tooth. (Credit: Kotov Lab/U. Michigan)

Synthetic tooth enamel

The reason why this structure is effective at absorbing vibrations, Kotov explains, is that the stiff nanoscale columns bending under stress from above create a lot of friction with the softer polymer surrounding them within the enamel. The large contact area between the ceramic and protein components further increases the dissipation of energy that might otherwise damage it.

Bongjun Yeom, a postdoctoral researcher in Kotov’s lab, recreated the enamel structure by growing zinc oxide nanowires on a chip. Then he layered two polymers over the nanowires, spinning the chip to spread out the liquid and baking it to cure the plastic between coats.

It took 40 layers to build up a single micrometer, or one thousandth of a millimeter, of enamel-like structure. Then, they laid down another layer of zinc oxide nanowires and filled it in with 40 layers of polymer, repeating the whole process up to 20 times.

These artificial teeth are as tough as real ones

Even molecular or nanoscale gaps between the polymer and ceramic would reduce the strength of material and the intensity of the friction, but the painstaking layering ensured the surfaces were perfectly mated.

“The marvelous mechanical properties of biological materials stem from great molecular and nanoscale adaptation of soft structures to hard ones and vice versa,” Kotov says.

Kotov’s group demonstrated that their synthetic tooth enamel approached the ability of real tooth enamel to defend itself from damage due to vibrations. Computer modeling of the synthetic enamel, performed by researchers at Michigan Technological University and the Illinois Applied Research Institute, confirmed that the structure diffused the forces from vibrations through the interaction between the polymer and columns.

Kotov hopes to see the synthetic enamel deployed in airplanes and other environments in which vibrations are inescapable, protecting structures and electronics. The challenge, he says, will be automating the production of the material.

The paper appears the journal Nature.

The Defense Advanced Research Projects Agency, NextGen Aeronautics, National Science Foundation, Department of Defense, and the National Research Foundation of Korea supported the work. The electron microscope used for the analysis was purchased with National Science Foundation grants.

Source: University of Michigan
